PTFE Coated Fiberglass Mesh Conveyor Belt for Food and Industrial Lines
PTFE-coated fiberglass mesh supplied as rolls or fabricated belts for continuous food processing, drying and packaging conveyors needing open-area airflow.
Product overview
PTFE-coated fiberglass mesh supplied as rolls or fabricated belts for continuous food processing, drying and packaging conveyors needing open-area airflow.
Product highlights
- Food-contact PTFE surface
- Non-stick release
- High open area for airflow
- Stable fiberglass weave
- Easy sanitation
- Fabricated belt options
Procurement data
Technical specifications
Final specifications are confirmed against operating conditions and order requirements.
| Product Name | PTFE Coated Fiberglass Mesh Conveyor Belt |
|---|---|
| Material | Food-contact PTFE coating on woven fiberglass mesh |
| Surface | Smooth PTFE-coated yarn surface with open-area release and controlled air passage |
| Reinforcement | Woven fiberglass mesh construction |
| Temperature Range | -70°C to 260°C |
| Airflow / permeability | Construction-dependent |
| Thickness Options | 0.75 mm, 0.95 mm, 1.20 mm, 1.45 mm or custom belt construction |
| Size Options | Belt widths from 300 mm to 2000 mm; rolls in 1000 mm, 1250 mm and 1500 mm widths; custom lengths |
| Color Options | Brown, black, blue or custom color by construction |
| Edge Type | Cut edge, bound edge, PTFE film edge, tracking strip or side guide |
| Shape Options | Mesh roll, endless conveyor belt, laced belt, edge-reinforced panel or cut sheet |
| Food Contact / Documents | Food-contact PTFE-coated fiberglass mesh is suitable for food processing conveyor applications. |
| Non-stick Performance | PTFE-coated mesh surface for clean release and easy sanitation |
| Custom Logo | OEM labels and belt identification marks are available for production lines. |
| Packaging Options | Roll packing, reinforced belt protection, serial labels and export cartons are available by requirement. |
| MOQ | One belt or one standard roll for established constructions; special weave and guidance systems are quoted per project |
| Sample Availability | Mesh samples and custom belt trial pieces can be prepared for line validation. |
| Lead Time | 7-12 working days for common rolls; 12-20 working days for endless belts with custom edge and tracking details |
| Applications | Bakery tunnel ovens, Snack cooling conveyors, Fruit and vegetable drying, Frozen-food processing, Heat-shrink packaging, Screen-print drying equipment |
End-use fit
Applications
Typical purchasing use cases for this product family.
- Bakery tunnel ovens
- Snack cooling conveyors
- Fruit and vegetable drying
- Frozen-food processing
- Heat-shrink packaging
- Screen-print drying equipment
Purchasing questions
Frequently asked questions
Product-specific answers for sampling, customization and production planning.
What mesh opening works best for bakery products?
Fine 1 x 1 mm or 2 x 2 mm mesh supports small items, while 4 x 4 mm mesh is a versatile choice for airflow on trays and cooling lines.
Can you add tracking guides and reinforced edges?
Yes. Belts can be supplied with edge binding plus tracking strips or side guides to suit the conveyor.
Can the belt be supplied with an endless joint?
Yes. Endless, laced and other project-specific joint options are available according to installation and maintenance requirements.
How are packaging, samples and lead time confirmed for PTFE Coated Fiberglass Mesh Conveyor Belt?
Roll packing, reinforced belt protection, serial labels and export cartons are available by requirement. Mesh samples and custom belt trial pieces can be prepared for line validation. 7-12 working days for common rolls; 12-20 working days for endless belts with custom edge and tracking details MOQ, packing configuration and delivery schedule are confirmed after the final material, dimensions and quantity are approved.
Discuss your requirement
Request a quote for PTFE Coated Fiberglass Mesh Conveyor Belt
Share dimensions, quantity, operating conditions, packaging and documentation needs. We will follow up with the next specification steps.
